PRODUCT PORTFOLIO

Scalable High-Current IVR Solutions

The ET21324X series represents a new class of integrated power solutions, combining high current density, scalability, and ultra-fast transient response. Built on Endura’s proprietary Bypass Dual Duty-Cycle Control (BDDC™) and AC Regulation (ACR) technologies, these multiphase step-down switching regulators deliver exceptional performance for the most demanding AI, CPU, GPU, and ASIC applications.

Close up photo of silicon chip manufacturing

HIGH-DENSITY POWER

Engineered to Unlock Peak Performance

The ET21324X is a 32-phase, high-efficiency step-down regulator capable of delivering up to 150A continuous and 220A instantaneous current—all within a compact 35mm² die.

Its ultra-high bandwidth enables super-fast load transient response, drastically reducing output voltage droop with minimal output capacitance.

SCALABLE POWER DELIVERY

Flexible Output Configurations

The ET21324X series can be configured for single, dual, triple, or quad outputs, allowing it to adapt to diverse system requirements. Multiple devices can also be connected in parallel to scale current capabilities even further.




                ET21324X
Quad Output
                ET21322X
Dual Output
                ET21321X
Single Output



                Vin (V)
                Vin (V)1.8
                Vin (V)1.8
                Vin (V)1.8


                Vout (V)
                Vout (V)0.3–1.4
                Vout (V)0.3–1.4
                Vout (V)0.3–1.4


                Outputs
                Outputs4
                Outputs2
                Outputs1


                TDC (A)
                TDC (A)150
                TDC (A)150
                TDC (A)150


                EDC (A)
                EDC (A)220
                EDC (A)220
                EDC (A)220


                Interface
                InterfacePMBus, AVS
                InterfacePMBus, AVS
                InterfacePMBus, AVS


                Frequency
                Frequency150MHz
                Frequency150MHz
                Frequency150MHz




ET21324X IVR series

Applications

Endura’s ET21324X IVR series is designed for high-density, high-performance computing environments where power integrity, efficiency, and speed are critical.

AI Processors

Handle the massive and dynamic workloads of modern AI accelerators with minimal voltage droop and ultra-fast response times, ensuring stable operation even under extreme power fluctuations.

CPU Icon depicting stylised computer chip

CPUs & GPUs

Deliver consistent, high-efficiency power across complex multi-core systems, enabling higher clock speeds and better thermal performance in data centers and advanced computing platforms.

ASICs & FPGAs

Provide precise power regulation for custom silicon and reconfigurable architectures, supporting the flexibility and precision required for domain-specific compute applications.

Icon depicting stack of chips to indicate density

High-Density Compute Platforms

Optimize performance-per-watt in compact, power-intensive environments by integrating scalable power management directly into the silicon.

Key Benefits

Compact Power, Massive Performance

Up to 150A continuous / 220A instantaneous current

32-phase multiphase design for superior load distribution

Ultra-fast transient response using ACR technology

Scalable architecture – parallel devices for extended current

Compact 35mm² footprint for high-density layouts

Package-agnostic compatibility (2.5D & 3D)

PMBus and AVS interface support for advanced power control

PROPRIETARY PRODUCT DATA

Achieve Your Full Power Potential

Detailed specifications, application notes, and design files for the ET21324X series are provided exclusively to qualified partners upon request.
